Semi-Automatic 200L Weighing Lubricants Oil Large Volume Latex Paint Filler Filling Machine
Description
Basic Info
| Model NO. | CD-BZD2 |
| Automatic Grade | Semi-Automatic |
| Material Type | Liquid |
| Filling Valve Head | Single-Head |
| Feed Cylinder Structure | Single-Room Feeding |
| Dosing Device | Capacity Cup |
| Filling Principle | Pressure |
| Packaging Container Lifting Structure | Pneumatic Lifting |
| Structure | Desktop |
| Packaging | Barrel |
| Packaging Material | Plastic |
| Product Name | Semi Automatic 200L Weighing Filling Machinee |
| Function | Liquid Weighing Filling Machine |
| Advantage | Easy Operation |
| Filling Volume | 25-35 Barrels/Hour |
| Applicable Bottle Height | Unlimited |
| Filling Capacity | 100-250kg |
| Power Source | 4kw |
| Weight | 180kg |
| Transport Package | Wooden Case |
| Specification | 3300*1300*1700 mm |
| Trademark | YZH |
| Origin | China |
| Production Capacity | 160-200 Barrels/Day |
Packaging & Delivery
Package size per unit product 330.00cm * 130.00cm * 170.00cm Gross weight per unit product 180.000kgProduct Description
Semi-automatic 200L weighing filling machine
Product Description
Semi-automatic 200L weighing filling machine Lubricants Oil Large Volume Latex Paint Filling Machine
This weighing filling machine system adopts weighing type filling.
Feeding method: continuous and stable feeding is required (using high-position tank for feeding)The feeding mechanism uses solenoid valves to perform fast and slow feeding respectively through cylinders.Filling method: ordinary conventional filling and lifting submerged filling.The weighing system consists of weighing brackets, sensors, weighing platform equipped with unpowered rollers and frame support and filling system.Pneumatic control system: control fast and slow feeding valve.
Feature:
1.The system adopts weighing type filling with high measuring accuracy and is not affected by materials.
2.The feeding valve composed of fast feeding and slow feeding can increase the filling speed and the filling accuracy.
3.The measurement range is large, and the measurement error is less than three thousandths.
4.The filling head adopts an anti-drip device, the filled material has no bubbles, and the effect is good.
Detailed Photos
Product Parameters
| System | weighing system |
| Power | 4KW |
| Filling volume | 25-35 barrels/hour |
| Applicable bottle height | Unlimited |
| Filling capacity | 100-250kg |
| Weight | 180KG |
| Dimensions | 3300*1300*1700 (length * width * height) |
Company Profile
Henan YZH Machine , manufacturer which specializes in the production of Automatic filling machine, Rotary filling machine, Labeling machine, Film shrinking machine, Capping machine, Plastic film blowing machine, Plastic bag making machine, sales of various filling and packing equipment, with professional installation and after-sales team, to provide you with high-quality technical support and perfect after-sales service.
Our factory located in Zhengzhou city , Henan province, which covers an area of 60000m2, through about 30 years development, now is has 178 staff, which including 23 engineers and technical persons.Our machines have been sold to many countries worldwide such as USA,Canada,Mexico, Argentina,France, Spain, Italy,and so on.
Welcome your cooperation with us .
After Sales Service
1.24 hours/day and 7 days/week for after-sales service, online guide etc.
2.Online guide to installation and commission, on-site service available if need.send rich practiced experience engineers to you to install and test the machine and train your worker for free.3.All of our equipment contain 1 year warranty.4.After one year,we can guide and help you to maintain the machines.5.Every 2 years,we can help to overhaul the complete machines for free.6.Send you spare part in lower price with fast delivery.
FAQ
Q1: What is the Warranty for the machine?A1: For the machine,we have 1 year warranty.If any quality problems occurred under normal condition in this period ,we will take on the cost of maintenance and replacement and other related cost.
Q2: How to operate and maintain the machine?A2: First, we will provide a professional and detailed USER GUIDE or VEDIOS to you with the machine; Second, we will debug the machine in the best status for you; At last, we also provide technical training service abroad.
Q3: How to get raw material or auxiliary material for the machine?A3: Our company has more than 20 years experience in this industry, we can help to supply you raw material and give you best solution for your production configuration.
